Solar Charge Controller- 60A MPPT

Solar Charge Controller- 60A MPPT

Regular price £230.00 GBP
Regular price £400.00 GBP Sale price £230.00 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.
Do you need canalside delivery? (*N.B. - If Yes enter billing address as your delivery address at checkout)

The 60A MPPT Solar Charge Controller for Solar Panels is an essential component for optimizing the performance of your solar energy system. With its Maximum Power Point Tracking (MPPT) technology, this charge controller efficiently converts the power generated by your solar panels, ensuring maximum energy harvest.


See downloads for detailed specification sheet

  • The most advanced MPPT technology to ensure high efficiency (>95%) of your solar system
  • Fully automated operation and auto 12/24/36/48V selection for lead acid batteries
  • 2 pairs of terminals (solar panel, battery) for wires up to 35mm2
  • Maximum solar panel voltage 150V
  • Maximum solar panel power 750W (12V) / 1500W (24V) / 2200W (36V) / 3000W (48V)
  • Temperature sensor for automatic compensation (-3mV/°C/2V)
  • Comprehensive electronic protection features
  • Communication port: RS485/RJ45 interface
  • Grounding: negative common ground
  • Current limiting function (60A)
  • Self-consumption: 98mA (12V) , 60mA (24V), 50mA (36V), 46mA (48V)
  • Working temperature: -25°C to +60°C (temperature derating above 40°C)
  • Size: 340 x 216 x 119 mm
  • Mounting dimensions: 260 x 224 mm
  • Weight: 4.5kg
  • Multiple mounting holes (7mm diameter) for ease of installation

Warranty and Safety Features
